10 December 2019 – New standards in long-endurance underwater navigation and automated subsea positioning have been set following the successful completion of a joint project led by subsea technology specialist Sonardyne International Ltd., with partners the National Oceanography Centre (NOC) and L3Harris.
The two-year, £1.4 million Precise Positioning for Persistent Autonomous Underwater Vehicles (P3AUV) project, part funded by Innovate UK, set out to integrate existing and emerging technologies to deliver a step-change in unmanned platform endurance and navigational precision.
In addition, the project also set out to increase the use of autonomy in offshore survey positioning operations using unmanned surface vessels (USVs), and in the process reducing risk to personnel, environmental impact and operating costs.
The final project trials, which also saw one of the NOC’s largest deployment of AUVs operating in swarms, were completed this month (December) in Loch Ness, Scotland.
“Sending autonomous and unmanned underwater vehicles (AUV/UUVs) out on missions that will last for weeks or even months, unaided by crewed ships is a shared vision held by the ocean science, offshore energy and defence sectors,” says Geraint West, Sonardyne’s Global Business Manager for Ocean Science. “But, current constraints on AUV or UUV operations, such as onboard battery capacity and navigational accuracy degradation over time, has meant that the role these vehicles have had to play has been largely restricted to relatively short deployments.
“As the only company that produces an all-in-one hybrid acoustic-inertial-Doppler navigation and communication solutions for AUVs and USVs, we were uniquely placed to collaborate with the NOC and L3Harris to realise the ambitious aims of the P3AUV project.
“By developing and integrating each organisation’s technologies, including our own SPRINT-Nav navigation instrument, we’ve proven it’s possible for underwater platforms to make more of their available onboard power and maintain navigational accuracy over long distances without external aiding.
“We’ve also proven the capability to autonomously calibrate networks of seafloor positioning transponders with an L3Harris C-Worker 5 USV to make offshore survey and construction operations faster and easier,” says West.
Using autonomous calibration techniques will remove the need for a manned vessel to perform this task, removing people from harms’ way, driving down fuel emissions and improving efficiencies.
“To put this into perspective, an offshore support or research vessel will typically burn some 3,000 tonnes of fuel annually and generate about 10,000 tonnes (equivalent) of greenhouse gases,” says James Cowles, L3Harris UK. “The environmental footprint of an independent ASV or AUV is, by comparison, negligible.”
“Combining all of these capabilities will bring about a step-change in AUV operations, providing a disruptive capability in the marine autonomy space,” says Matt Kingsland, NOC. “Indeed, reducing the cost and improving the navigation precision of autonomous ocean science in remote areas could bring a disruptive capability to a wide variety of applications.”
P3AUV has been supported by funding through Innovate UK’s research and development competition for robotics and artificial intelligence in extreme and challenging environments.
Central to the P3AUV project’s achievement is the vehicle’s inertial navigation system (INS) and acoustic technologies. Low power sensors have much lower navigation accuracy and often have to surface to correct positioning error with a GPS fix. But, by integrating low and high-power sensors to work together, P3AUV is getting the “best of both worlds”; high performance at much lower power consumption.
The project also involved improving positioning accuracy when subsea vehicles transition through the water column by using the acoustic Doppler current profiler (ADCP) capability in Sonardyne’s SPRINT-Nav hybrid navigation instrument and a second Syrinx Doppler velocity log (DVL) on the vehicle. This enables the vehicle to build a layer by layer profile of the water column velocities that can be used as tracking layers.
Photo courtesy Sonardyne
